BWN460 BWSENSING Dual-axis Inclinometer BWN460 Product Introduction:

Designed by Bewis Sensing Technology LLC, BWN460 is a cost-effective digital dual-axis inclinometer which output mode is RS485 and TTL optional.

Shared:

Technical Specifications

Accuracy: 0.01°

Resolution: 0.001°

Measuring axis: X-Y

Measuring range: ±60°

Power supply DC: 9-35V

Output: RS485, TTL optional

Wide operating temperature: -40℃~+85℃

Store temperature: -55℃~+100℃

Zero temperature drift: ±0.001°/℃



Product Advantages
1522039676218109.png Accuracy1522110325448404.png Resolution
0.01°0.001°


1522039614484057.png Measuring range1522039632548392.png Zero temperature drift
±30°±0.001°/℃


1522039650496055.png MTBF1522039663627482.png Protection class
≥100000 hoursIP67
