●Adopting the high-precision resistance strain gauge principle
●Built-in EtherCAT communication module
●High precision and strong anti-eccentric load capacity
●Accept custom specifications
Shared：
Range | Fx, Fy | N | 500 |
Fz | N | 500 | |
Mxyz | N.m | 12 | |
Display Accuracy | Fx, Fy | N | 0.5 |
Fz | N | 0.5 | |
Mxyz | N.m | 0.05 | |
Sampling frequency | Hz | 1000 | |
Nonlinear | %F.S | ±0.5 | |
Inter axis coupling | %F.S | ±2 | |
Repeatability | %F.S | ±0.1 | |
Temperature Effect On Zero | %F.S/10℃ | ±0.1 | |
Temperature Effect On Output | %F.S/10℃ | ±0.1 | |
Operating temperature range | ℃ | -10°+40 | |
Safe Overload | %F.S | 150 | |
Excitation | V DC | 9~24 | |
Sealing grade | Ip64 | ||
Material | aluminum alloy | ||
FLEXIBLE CABLE | 1 inlet and 1 outlet, each 0.5 meters | ||
-
