●Dual axis inclination measurement
●High accuracy: 0.001°
●Cross axis error: 0.001°
●Baud rate 2400~115200 adjustable
●IP67 protection level
●Wide voltage input: 9-36VDC
●Output frequency 5~ 100Hz adjustable
●Accept OEM customization
Parameter | Condition | range of values | |
Voltage (V) | 9-36 | ||
Current (mA) | No load | 20-40 | |
Operating temperature(℃) | -40+85 | ||
Storage temperature(℃) | -55~+100 |
Performance index
Measurement Range (°) | Condition | ±5 | ±15 | ±30 | ||
Measurement axis | Mutually perpendicular | X-Y | X-Y | X-Y | ||
Accuracy (°) | Room temperature | 0.001 | 0.003 | 0.005 | ||
Cross-axis error (°) | -40~85℃ | 0.001 | 0.003 | 0.005 | ||
Resolution (°) | be completely still | 0.0005 | ||||
Zero point temperature drift (°/°C) | -40~85℃ | ±0.0007 | ||||
Power-on start-up time | <3s | |||||
Output frequency (Hz) | 5-100Hz adjustable | Up to 100 | ||||
baud | tunable | 2400~115200 | ||||
Mean time between failures MTBF | ≥90000 h | |||||
Electromagnetic compatibility | According to GBT17626 | |||||
Insulation resistance | ≥100 MΩ | |||||
Impact resistance | 2000g,0.5ms,3 times/axis |
