Working current

80mA

Operating temperature

-40℃~+85℃

Storage temperature

-55℃~+100℃

Accuracy

≤2° (RMS) after spatial calibration in a favourable magnetic environment

Resolution

0.1°

Power-Up Repeatability

0.5° (RMS)

Pitch

Measurement Range

±90°

Accuracy

Static ≤0.05° (1σ)    Dynamic ≤0.5° (RMS)

Dynamic ≤0.5° (RMS)    Dynamic ≤0.5° (RMS)

Resolution

0.05°

Repeatability

0.05° (RMS)

Roll

Range

±180° (pitch angle ≤±75°)

Accuracy

Static ≤ 0.01° (1σ)    Dynamic ≤ 0.5° (RMS)

Dynamic ≤0.5° (RMS)    Dynamic ≤ 0.5° (RMS)

Resolution

0.05°

Repeatability

0.05° (RMS)

Environment

Baud Rate

9600–921600 (default 115200)

User Calibration Procedure

Calibration Method

Rapid calibration

Range

±8g

±400°/s

±1000°/s

±8Gauss

Noise density

200 µg/√Hz

1.5mdps/√Hz

5 mdps/√Hz

1.5 mGauss/√Hz

Bandwidth

100Hz

100Hz

-

Zero bias stability (10-second smoothing)

30ug

10 °/h

-

Protection level

Not specified (does not represent final product protection rating)

Shell material

Magnesium-aluminium alloy anodised finish

Installation

2 x M2 copper bolts
