Resolution

0.1°

Repeatability

0.5°

Compass inclination parameter

Pitch accuracy

0.15º

Roll accuracy

0.15º

Resolution

0.01°

Inclination

±30°

Calibration

Hard magnetic calibration

Yes

Soft magnetic calibration

Yes

Mechanical parameter

Dimension

L55 x W37 x H24 (mm)

Weight

115g

Output mode

RS232/485/TTL interface

Interface characteristics

Start-up delay

<3s

Maximum output frequency

50Hz

RS232 communication rate

2400 to 115200 baud rate

Environment

Anti-vibration performance

2000g
