Power voltage(V)

9

12

35

Working Current(mA)

No load

20

30

40

Operating temperature(℃)

-40

85

Storage temperature (℃)

-55

100

Measurement axis

Mutually perpendicular

X

Accuracy(°)

Room Temperature

0.3

Resolution(°)

Completely still

0.03

Cross axis error(°)

-40〜85℃

0.3

Start-up time

＜3s

Output frequency（Hz）

5-100Hz adjustable

Up to 100

Mean time between failures MTBF

≥90000 h

Electromagnetic compatibility

According to GBT17626

Insulation resistance

≥100 MΩ

Impact resistance

2000g，0.5ms，3 times/axis

Weight (g)

210（ Without outer packaging ）
