●High accuracy 0.001°
●Biaxial Inclination Measurement
●Cross axis error: 0.001°
●Baud rate 2400~115200adjustable
●Temperature drift 0.0003°/℃
●Wide voltage input 9-36V DC
●Output frequency 5~100Hz adjustable
●RS485/RS232/TTL optional
Performance Index
Measurement Range (°) | Condition | ±5 | ±15 | ||
Measurement axis | Mutually perpendicular | X-Y | X-Y | ||
Accuracy (°) | Room temperature | 0.001 | 0.003 | ||
Cross axis error (°) | -40~85℃ | 0.001 | 0.003 | ||
Resolution (°) | Completely still | 0.0001 | |||
Zero bias (°/℃) | -40~85℃ | ±0.0003 | |||
Start-up time | <3s | ||||
Output frequency (Hz) | 5-100Hz adjustable | Up to 100 | |||
Baud rate | Adjustable | 2400~115200 | |||
Mean time between failures MTBF | ≥90000 h/time | ||||
Electromagnetic compatibility | According to GBT17626 | ||||
Insulation resistance | ≥100MΩ | ||||
Impact resistance | 2000g,0.5ms,3 times/axis |
