● Single axis inclination monitoring
● Alarm threshold can be set arbitrarily
● Single line output alarm
● Wide voltage input 9~36V
● Supports external zero setting function
● High vibration resistance >2000g
● high resolution:0.01°
● Wide tempe
Parameter | Condition | Min | Typ | Max | |||
Power voltage(V) | 9 | 12 | 36 | ||||
Working current(mA) | Horizontal no-load | 80 | |||||
NC Maximum current (mA) | 100 | ||||||
Operating temperature(℃) | -40 | 85 | |||||
Storage temperature(℃) | -55 | 100 |
Parameter | Condition | DIS332 | |
Measurement Range(°) | ±180 | ||
Accuracy(°) | Dynamic 2°/ Static 0.1° | ||
Measurement axis | X | ||
Alarm axis | X | ||
Zero temperature drift(°/℃) | -40~85℃ | ±0.01 | |
Response frequency (Hz) | 100 | ||
Communication cable | 10-core cable, single 0.15mm² | ||
Weight (g) | About 220(Cable 1.5m,without package) |
